Build Your Chassis
1967-72 GMC Truck
Select and customize the performance package engineered for your driving style.
Ultimate 4x4
Click to select
View Standard Equipment
Package Price
$64,875.00
Ultimate 4×4 Package
Complete at $64,875.00
Jig welded, full cleaned & prepped 0.180″-wall mandrel bent frame assembly
2×4 front and rear rails, 2×6 center frame structure
Transmission-specific crossmember & engine mount kit
AME fabricated front axle housing, 3.5″ x 0.500″ wall tubes, fabricated inner C and outer knuckle, Superduty 8-lug wheel bearings, chromemoly axle shafts, Currie Truetrac center sections
AME fabricated rear axle housing, 3.5″ x 0.500″ wall tubes, forged housing ends, Superduty 8-lug wheel bearings, chromemoly full float axle shafts, Currie center section
3-link front suspension w/ 2.5″ x 1/4″ wall lower links, 2″ x 1/4″ wall upper link, with large Johnny Joints
Extra long rear trailing arms with 2″ x 1/4″ wall upper triangulated links and large Johnny Joints
40-Spline heavy duty new steering box with double shear pitman arm
Splined front and rear sway bars with solid steel double shear arms
Fox 2.5 Factory Race Emulsion front and rear coilovers with springs & hardware
Fox Factory Race nitrogen charged bump stops & heavy duty axle limit straps
Wilwood 4×4 brake package, Aero 6 piston w/ 13″ x 1.25″ front rotors & FSLI 4-piston w/ 13″ x 1.25″ rear rotors and electric parking brake
Black coated links & axle housings
Pre-assembly service with preliminary alignment
Foundation 4x4
Click to select
View Standard Equipment
Package Price
$60,360.00
Foundation 4×4 Package
Complete at $60,360.00
Jig welded, full cleaned & prepped 0.180″-wall mandrel bent frame assembly
2×4 front and rear rails, 2×6 center frame structure
Transmission-specific crossmember & engine mount kit
AME fabricated front axle housing, 3.5″ x 0.500″ wall tubes, fabricated inner C and outer knuckle, Superduty 5 or 6-lug wheel bearings, chromemoly axle shafts, Currie center section
AME fabricated rear axle housing, 3.5″ x 0.500″ wall tubes, forged housing ends, 5 or 6-lug Hytuf semi-float axle shafts, Currie Truetrac center sections
3-link front suspension w/ 2.5″ x 1/4″ wall lower links, 2″ x 1/4″ wall upper link, with large Johnny Joints
Extra long rear trailing arms with 2″ x 1/4″ wall upper triagulated links and large Johnny Joints
40-Spline heavy duty new steering box with double shear pitman arm
Splined front and rear sway bars with solid steel double shear arms
Fox 2.5 Factory Race Emulsion front and rear coilovers with springs & hardware
Performance urethane foam bump stops
Wilwood 4×4 brake package, Aero 6 piston w/ 13″ x 1.25″ front rotors & FSLI 4-piston w/ 13″ x 1.1″ rear rotors with parking brake
Black coated links & axle housings
Pre-assembly service with preliminary alignment
